DESCRIPTION |
SPECIFICATION |
UNIT |
비고 |
Winding Diameter |
600 |
mm |
- |
Winding Length |
2000 |
mm |
- |
Weight of Mandrel |
100 |
kg |
- |
No. of Spindle |
1 |
per
|
- |
Height of Spindle |
900 |
mm |
- |
Winding Angle |
0/89 ° |
deg |
- |
No. of Axis |
2 |
axis
|
- |
|
|
|
|
|
| |
 |
| |
|
|
DESCRIPTION |
SPECIFICATION |
UNIT |
비고 |
Winding Diameter |
700 |
mm |
- |
Winding Length |
500 |
mm |
- |
Weight of Mandrel |
10 |
kg/per
|
- |
No. of Spindle |
10 |
per
|
- |
Height of Spindle |
400 |
mm |
- |
Winding Angle |
0/89 ° |
deg |
- |
No. of Axis |
3 |
axis
|
- |
|
|
|
|
|
| |
 |
| |
|
|
DESCRIPTION |
SPECIFICATION |
UNIT |
비고 |
Winding Diameter |
800 |
mm |
- |
Winding Length |
4000 |
mm |
- |
Weight of Mandrel |
200 |
kg/per
|
- |
No. of Spindle |
4 |
per
|
- |
Height of Spindle |
600 |
mm |
- |
Winding Angle |
0/89 ° |
deg |
- |
No. of Axis |
3 |
axis
|
- |
|
|
|
|
|
| |
 |
| |
|
|
DESCRIPTION |
SPECIFICATION |
UNIT |
비고 |
Winding Diameter |
950 |
mm |
- |
Winding Length |
6800 |
mm |
- |
Weight of Mandrel |
1000 |
kg/per
|
- |
No. of Spindle |
1 |
per
|
- |
Height of Spindle |
950 |
mm |
- |
Winding Angle |
0/89 ° |
deg |
- |
No. of Axis |
3 |
axis
|
- |
|
|
|
|
|
| |
 |
| |
|
|
DESCRIPTION |
SPECIFICATION |
UNIT |
비고 |
Winding Diameter |
300 |
mm |
- |
Winding Length |
3000 |
mm |
- |
Weight of Mandrel |
200 |
kg/per
|
- |
No. of Spindle |
4 |
per
|
- |
Height of Spindle |
600 |
mm |
- |
Winding Angle |
0/89 ° |
deg |
- |
No. of Axis |
3 |
axis
|
- |
|
|
|
|
|
| |
 |
| |
|
|
DESCRIPTION |
SPECIFICATION |
UNIT |
비고 |
Winding Diameter |
950 |
mm |
- |
Winding Length |
7000 |
mm |
- |
Weight of Mandrel |
1000 |
kg/per
|
- |
No. of Spindle |
1 |
per
|
- |
Height of Spindle |
700 |
mm |
- |
Winding Angle |
0/89 ° |
deg |
- |
No. of Axis |
3 |
axis
|
- |
|
|
|
|
|
| |
|
